FRAME
28", lite AL-6061 tubing, PowerTube battery
FORK
Suntour Mobie 25 Air, LOR DS, 100 mm, 15x100 mm axle
DRIVE UNIT
Bosch Performance Line CX, Gen. 4, 250 W, 36 V, max. 25 km/h
BATTERY
Bosch PowerTube, 36 V Li Ion, 625 Wh
DISPLAY
Bosch Kiox
SHIFTERS
Enviolo, automatic, included in Kiox display
CRANKSET
FSA CK-745, belt, 50t
BB-SET
Bosch, Isis
CHAIN
Gates CDX Carbon Drive Belt, Center-Track
CASSETTE
Gates CDX, 24t
BRAKE LEVERS
Shimano Alfine, BL-S7000, hydraulic disc brake
BRAKES
Shimano Alfine, BR-S7000, hydraulic disc brake
ROTOR
Shimano SM-RT54, 180 mm / Shimano SM-RT26, 160 mm
HANDLEBAR
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm
H'STEM
BGM E-Bike, adjustable, for Kiox integration
SEATPOST
BGM Pro
SEAT
Selle Royal Lookin BGM Basic Athletic
HEADSET
Acros, A-Headset, semi-integrated, 1.5", with integrated cable routing
HUB (FRONT)
Shimano HB-MT400, centerlock, disc, 15x100 mm axle
HUB (REAR)
Enviolo Trekking Automatic, 6-bolt, disc
SPOKES
Sapim Leader
RIMS
Ryde Rival 23, disc, eyelets
FRONT TIRE
Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 55-622, Tube: Schwalbe AV19
REAR TIRE
Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 55-622, Tube: Schwalbe AV19
LIGHTS
Front: B&M IQ-XS, 80 Lux, LED, Rear: B&M Toplight Line brex, LED, with brakelight
RACK & FENDERS
Fender: Racktime Alumee, Carrier: Racktime E-Ville carrier, Snapit 2.0 System
PEDALS
Trekking alloy
ACCESSORIES
Kickstand: Syncros
APPROX WEIGHTS IN KG
29,2
FRAME SIZE
46/50/54/58 cm
GRIPS
BGM Comfort, Ergo, double density, clamp version
MAX. SYSTEM WEIGHT
160,0 kg
