Frame
26", Lite AL-6061 tubing, prepared for heavy duty front and long rear rack, PowerPack battery
Fork
BGM cargo, CrMo rigid fork, extra strong, 15x100 mm axle
Drive Unit
Bosch Cargo Line, Gen. 4, BES3, 250 W, 36 V, max. 25 km/h
Battery
Bosch PowerPack, 36 V Li Ion, 725 Wh
Display
Bosch LED Remote with Intuvia 100
Charger
Bosch Standard Charger, 4A
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shifters
Shimano Deore, SL-M6100, 1x12-speed, rapidfire plus-shifter
Crankset
FSA CK-320, 38t, with chaincover
BB-Set
Bosch, Isis
Chain
KMC e12 EPT
Cassette
Shimano Deore, CS-M6100, 10-51t
Brake Levers
Magura CMe5, hydraulic disc brake
Brakes
Magura CMe5, hydraulic disc brake, 4-piston
Rotor
Front: Magura MDR-C, 203 mm; Rear: Magura MDR-C, 180 mm
Handlebar
BGM Pro, riserbar, rise: 50 mm
H'Stem
Satori Python, adjustable
Seatpost
BGM Pro
Seat
Syncros Capilano Trekking Memory Foam
Headset
Cane Creek Visco-Set, A-Headset, semi-integrated, tapered (fork) / FSA IS-3E, A-Headset, 1-1/8" (steering tube)
Hub (Front)
BGM Pro Cargo, 6-bolt, disc, 15x110 mm axle, quad bearing
Hub (Rear)
Shimano Deore XT, FH-M8110-B, centerlock, disc, 12x148 mm axle
Spokes
Sapim Leader
Rims
Ryde Andra 40, disc
Front Tire
Schwalbe Super Moto-X, Greenguard, 62-559; Tube: Impac AV26
Rear Tire
Schwalbe Super Moto-X, Greenguard, 62-559; Tube: Impac AV26
Lights
Front: B&M IQ-XS, 80 Lux, LED; Rear: B&M Toplight 2 C, LED
Rack
BGM custom carrier, front & rear, with Atran AVS system & easy fit window for Thule Yepp (rear)
Pedals
Marwi SP-827, sandblock
Accessories
Kickstand: Ursus Jumbo Evo, 2-legged
Approx Weight in KG
37,2
Color
Shiny mortar grey
Fender
Curana Apollo, with stainless stays
Frame Size
S/L
Grips
BGM Comfort, Ergo, double density, lock-on
Max. System Weight
190,0 kg
Overall Weight
The overall weight includes the bike, the rider, the equipment and possible additional luggage.
